Locking Device - Shrink Disc
| ORDER CODE : |
| For a shaft with d=30mm and a transmissible torque value lower than or equal to 412Nm |
| KBS 19/1 - 30 X 60 |
KBS 19/1 |
| Recommended machining tolerances: |
| shaft h 9 |
